7
DBR10/DBR12/DBR15
DIMENSIONS（寸法図）
376
601
150
For pole
˳ 35mm
2-M8 depth
17mm
Unit（単位）: mm
102
M8 depth 17mm
408
50°
348
162
152
308
493
289
148
120
138
For pole ˳35mm
2-M8 depth 17mm
Unit（単位）: mm
50°
336
455
700
150
For pole ˳35mm
2-M8 depth 17mm
Unit（単位）: mm
126
M8 depth 17mm
464
50°
378
173
163
DBR15
DBR12
DBR10
