Parameter Lists
25 Male Vocal 1
PEAKING PEAKING PEAKING PEAKING
G –0.5 dB 0.0 dB +2.0 dB +3.5 dB
F 190 Hz 1.00 kHz 2.00 kHz 6.70 kHz
Q 0.11 4.5 0.56 0.11
26 Male Vocal 2
PEAKING PEAKING PEAKING H.SHELF
G +2.0 dB –5.0 dB –2.5 dB +4.0 dB
F 170 Hz 236 Hz 2.65 kHz 6.70 kHz
Q 0.11 10 5.6 —
27 Female Vo. 1
PEAKING PEAKING PEAKING PEAKING
G –1.0 dB +1.0 dB +1.5 dB +2.0 dB
F 118 Hz 400 Hz 2.65 kHz 6.00 kHz
Q 0.18 0.45 0.56 0.14
28 Female Vo. 2
L.SHELF PEAKING PEAKING H.SHELF
G –7.0 dB +1.5 dB +1.5 dB +2.5 dB
F 112 Hz 335 Hz 2.00 kHz 6.70 kHz
Q — 0.16 0.2 —
29
Chorus &
Harmo
PEAKING PEAKING PEAKING PEAKING
G –2.0 dB –1.0 dB +1.5 dB +3.0 dB
F 90 Hz 850 Hz 2.12 kHz 4.50 kHz
Q 2.8 2 0.7 7
30 Total EQ 1
PEAKING PEAKING PEAKING H.SHELF
G –0.5 dB 0.0 dB +3.0 dB +6.5 dB
F 95 Hz 950 Hz 2.12 kHz 16.0 kHz
Q 7 2.2 5.6 —
31 Total EQ 2
PEAKING PEAKING PEAKING H.SHELF
G +4.0 dB +1.5 dB +2.0 dB +6.0 dB
F 95 Hz 750 Hz 1.80 kHz 18.0 kHz
Q 7 2.8 5.6 —
32 Total EQ 3
L.SHELF PEAKING PEAKING H.SHELF
G +1.5 dB +0.5 dB +2.0 dB +4.0 dB
F 67 Hz 850 Hz 1.90 kHz 15.0 kHz
Q — 0.28 0.7 —
No. Title
Parameter
LOW LOW-MID HIGH-MID HIGH
33 Bass Drum 3
PEAKING PEAKING PEAKING PEAKING
G +3.5 dB –10.0 dB +3.5 dB 0.0 dB
F 118 Hz 315 Hz 4.25 kHz 20.0 kHz
Q 2100.4 0.4
34 Snare Drum 3
L.SHELF PEAKING PEAKING PEAKING
G 0.0 dB +2.0 dB +3.5 dB 0.0 dB
F 224 Hz 560 Hz 4.25 kHz 4.00 kHz
Q — 4.5 2.8 0.1
35 Tom-tom 2
L.SHELF PEAKING PEAKING H.SHELF
G –9.0 dB +1.5 dB +2.0 dB 0.0 dB
F 90 Hz 212 Hz 5.30 kHz 17.0 kHz
Q — 4.5 1.2 —
36 Piano 3
PEAKING PEAKING PEAKING H.SHELF
G +4.5 dB –13.0 dB +4.5 dB +2.5 dB
F 100 Hz 475 Hz 2.36 kHz 10.0 kHz
Q 810 9 —
37 Piano Low
PEAKING PEAKING PEAKING H.SHELF
G –5.5 dB +1.5 dB +6.0 dB 0.0 dB
F 190 Hz 400 Hz 6.70 kHz 12.5 kHz
Q 10 6.3 2.2 —
38 Piano High
PEAKING PEAKING PEAKING PEAKING
G –5.5 dB +1.5 dB +5.0 dB +3.0 dB
F 190 Hz 400 Hz 6.70 kHz 5.60 kHz
Q 10 6.3 2.2 0.1
39 Fine-EQ Cass
L.SHELF PEAKING PEAKING H.SHELF
G –1.5 dB 0.0 dB +1.0 dB +3.0 dB
F 75 Hz 1.00 kHz 4.00 kHz 12.5 kHz
Q — 4.5 1.8 —
40 Narrator
PEAKING PEAKING PEAKING H.SHELF
G –4.0 dB –1.0 dB +2.0 dB 0.0 dB
F 106 Hz 710 Hz 2.50 kHz 10.0 kHz
Q 470.63 —
No. Title
Parameter
LOW LOW-MID HIGH-MID HIGH
■ EQ Parameters
LOW/HPF LOW-MID HIGH-MID HIGH /LPF
Q
0.1–10.0 (41 points)
low shelving HPF
0.1–10.0 (41 points)
0.1–10.0 (41 points)
high shelving LPF
F 21.2 Hz–20 kHz (1/12 oct step)
G
±18 dB (0.1 dB step)
HPF: on/off
±18 dB (0.1 dB step)
±18 dB (0.1 dB step)
LPF: on/off
