98
Function Tree/Function List
01X Owner’s Manual
Before Using Basics Section AppendixGetting Started Reference
EQ HIGH-MID FREQUENCY/EQHL-F
q
– i
(t)
21.2Hz – 20.0kHz
Adjusts the frequency.
No
EQ LOW Q/EQL-Q
q
– i
(r)
10.0 – 0.10
Determines the bandwidth of the EQ processing.
No
EQ ON/OFF
z
– ,
(z)
ON/OFF
Turns the EQ on or off. The L and R settings of the ST IN channel’s EQ are
linked together.
No u
ATT (Attenuate) (Selected Channel only)
(w)- 96.0dB – +12.0dB
Determines the amount of pre-EQ signal attenuation in dB.
No t
■ EQ LIBRARY (Selected Channel only)
(This can be called up by pressing the same EQ button twice in a row. For example: [EQ LOW] → [EQ LOW])
See EQ High (see below)
No
EQ HIGH [INTERNAL] → ([SELECTED CHANNEL]) → [EQ HIGH]
EQ HIGH GAIN/EQH-G
q
– i
(y)
-18.0dB – +18.0dB
Adjusts the gain level. When Q is set to LPF, this turns the filter on or off.
Pressing the [EQ LOW] and [EQ HIGH] buttons simultaneously resets all
band parameters (gain, frequency and Q) for the selected channel.
No
EQ HIGH FREQUENCY/EQH-F
q
– i
(t)
21.2Hz – 20.0kHz
Adjusts the frequency.
No
EQ HIGH Q/EQH-Q
q
– i
(r)
LPF, 10.0 – 0.10,
H.SHELF
Determines the bandwidth of the EQ processing. When Q is set to LPF, the
gain control turns the filter on or off.
No
EQ ON/OFF
z
– ,
(z)
ON/OFF
Turns the EQ on or off. The HIGH-band EQ functions as a low-pass filter
when the Q parameter is set to LPF. It functions as a shelving-type EQ when
the Q parameter is set to H.SHELF. The L and R settings of the ST IN chan-
nel’s EQ are linked together.
No u
ATT (Attenuate) (Selected Channel only)
(w)- 96.0dB – +12.0dB
Determines the amount of pre-EQ signal attenuation in dB.
No t
Knob
Function name/
settings
Explanation Prompt
Related
pages
Block
diagram
[PAGE SHIFT] + DISPLAY [ / ]
