Yamaha DSP-AX750SE - Impedance Selector

RX-V750/DSP-AX750/DSP-AX750SE
RX-V650/HTR-5760
RX-V750/DSP-AX750/DSP-AX750SE
RX-V650/HTR-5760
3
Caution:
1. As the melting point temperature of the lead free solder is
about 30°C to 40°C (50°F to 70°F) higher than that of the
lead solder, be sure to use a soldering iron suitable to
each solder.
2. If lead solder must be used, be sure to remove lead-free
solder from each terminal section of the parts to be re-
placed and from the area around it completely before sol-
dering, or make sure that the lead free solder and lead
solder melt together fully.
注意：
1. 無鉛ハンダの融点温度は通常の鉛入りハンダに比べ30〜
40 ℃程度高くなっていますので、それぞれのハンダに
合ったハンダごてをご使用ください。
2. 鉛入りハンダを使わざるを得ない場合は、あらかじめ交
換する部品端子部やその周辺部の無鉛ハンダをすべて取
り除くか、あるいは無鉛ハンダと鉛入りハンダが十分に
溶けた状態となるようにハンダ付けしてください。
■ IMPEDANCE SELECTOR
WARNING:
Do not change the setting of the IMPEDANCE SELECTOR
switch when the unit power is switched on, as doing so may
damage the unit.
IMPEDANCE SELECTOR switch
