52 Owner’s Manual
KIT Setting Area (KIT)
1 Hi-hat function (HH Func)
Use this parameter to specify how a hi-hat controller con-
nected to the HI-HAT CONTROL jack is to function.
• hi-hat ........ The hi-hat controller will function in the stan-
dard way for playing the hi-hat cymbal.
• MIDI......... When you step on the hi-hat controller, a MIDI
message is output in line with the settings made
on the Hi-hat MIDI Channel page (KIT7-4) and
the Hi-hat MIDI Type page (KIT7-5).
• When this parameter is set to “hi-hat” and “on” has been selected on
the Send Hi-hat Controller page (UTIL5-3), Control Change 4 mes-
sages corresponding to the degree to which the hi-hat controller is
depressed will be sent to external MIDI devices on MIDI channel 10.
• When this parameter is set to “MIDI”, MIDI messages are sent regard-
less of the selection made on the Send Hi-hat Controller page (UTIL5-
3).
1 Hi-hat MIDI channel (HH MIDI ch)
If “MIDI” has been selected on the Hi-hat Function page
(KIT7-3), use this parameter to set the MIDI channel for out-
put of MIDI messages generated by the hi-hat controller.
• If “hi-hat” has been selected on the Hi-hat Function page (KIT7-3), this
setting will be displayed as “--” and modification will not be possible.
1 Hi-hat MIDI type (HHMIDIType)
If “MIDI” has been selected on the Hi-hat Function page
(KIT7-3), use this parameter to set the type of MIDI message
generated by the hi-hat controller.
• If “hi-hat” has been selected on the Hi-hat Function page (KIT7-3), this
setting will be displayed as “---” and modification will not be possible.
1 Trigger setup link (TrgSetupLink)
Use this parameter to specify the trigger setup to be used
when the current kit is selected. A trigger setup can be
assigned to each different drum kit. These setups are identi-
fied using a category (P for Preset, U for User) and a number,
and you can move the cursor using the [B]/[C] buttons to
set these individually. Select “off” if the currently selected
drum kit does not need a special trigger setup.
• If TrgSetupLink is set to “off”, the trigger setup selected on the Startup
Tr igger page (UTIL1-5) will be loaded by default whenever the DTX-
MULTI 12 is turned on. (See page 83.) Following this, the trigger setup
can be freely changed on the Select Trigger Setup page (TRG1). (See
page 100.)
KIT7-3 Hi-hat Function page
Settings hi-hat or MIDI
KIT7-4 Hi-hat MIDI Channel page
Settings 1 to 16
KIT7-5 Hi-hat MIDI Type page
Settings
CC01 to CC95 (Control Change), AT (After-
touch), PBup (Pitch bend up), or PBdwn
(Pitch bend down)
KIT7-3≥≥≥<OTHER>
≥HH≥Func=hi-hat
1
NOTE
KIT7-4≥≥≥<OTHER>
≥HH≥MIDI≥ch=10
1
NOTE
KIT7-5≥≥≥<OTHER>
HHMIDIType=CC01
1
NOTE
KIT7-6 Trigger Setup Link page
Settings off, P01 to P05, or U01 to U10
KIT7-6≥≥≥<OTHER>
TrgSetupLink=P01
1
NOTE
