– 30 –
6. Install a new gasket and the oil drain bolt, and then
tighten the bolt.
7. Add engine oil to the upper level.
1 Upper level
Be sure no foreign material enters the crankcase.
8. Install the oil filler cap, the rubber cap and the cap.
9. Install the cover and the screw.
Oil drain bolt tightening torque:
17 Nm (1.7 m·kgf, 12 ft·lbf)
Recommended engine oil:
å
YAMALUBE 4 (10W-40),
SAE 10W-30 or 10W-40
∫
SAE #30
ç
SAE #20
∂
SAE 10W
Recommended engine oil grade:
API Service SE type or higher
Engine oil quantity:
0.6 L (0.63 US qt, 0.53 Imp qt)
700-006a
1
0°C
å
YAMALUBE 4 (10W-40)
∂
SAE 10W
ç
SAE #20
∫
SAE #30
32°F
25°C
80°F
