– 36 –
2. Replace the blown fuse with one of proper amper-
age.
TIP
If the fuse immediately blows again, consult a Yamaha
dealer.
3. Install the battery box and the cover.
Specified fuse: 10 A
779-070a
788-008
1
2
FUSE REPLACEMENT
(For EF3000iSE, EF3000iSEB)
Be sure to use specified fuse. A wrong fuse will
cause electrical system damage and A FIRE HAZ-
ARD.
Be sure the engine switch is turned to “STOP” to
prevent accidental short circuiting.
1. Remove the cover and the battery box.
1 Cover
2 Battery box
Battery box bolt tightening torque:
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Cover bolt tightening torque:
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
