2-7
E
EMU01155
Throttle Friction Adjusting Screw
A friction device in the remote control box
provides adjustable resistance to move-
ment of the remote control lever, and can be
set according to operator preference. An
adjusting screw is located on the front of the
remote control box.
WARNING
Do not overtighten the friction adjusting
screw. If there is too much resistance, it
may be difficult to move the lever, which
could result in an accident.
@
Resistance Screw
Increase Turn clockwise
Decrease Turn counterclockwise
