2-10
E
EMU01617
DIG ITAL TAC H O METE R
This gauge contains the tachometer, trim
meter, hour meter, low oil pressure warning
indicator, and the overheat warning indica-
tor.
1
Tachometer
2
Trim meter
3
Hour meter
4
Low oil pressure warning indicator
5
Overheat warning indicator
6
Set button
7
Mode button
NOTE:
@
All segments of the display will light momen-
tarily after the main switch is turned on and
will return to normal thereafter.
@
EMU00136
Tachometer
This meter shows the engine speed.
