4-3
6X4 MULTI-FUNCTION TILLER HANDLE
TILLER HANDLE KIT CONTENTS
50-90, F40-F115
KIT P/N:6X4-42101-01
F25
KIT P/N:6X4-42103-02
HANDLE FITTING KIT CONTENTS
Select the fitting kit corresponding with the model.
F115
KIT P/N:6X4-42102-00
Part name Part No. Q’ty Remarks
Tiller handle assy 6X4-42101-01 1 With PTT switch (Top), Required fitting kit.
Setup manual 6X4-2819K-11 1 English
Part name Part No. Q’ty Remarks
Grommet 2 65W-42725-21 1
Tiller handle assy 6X4-42101-22 1 With PTT switch (Top)
Lock nut 90185-10051 2 M10
Steering friction assy 65W-42508-00 1
Setup manual 6X4-2819K-11 1 English
Part name Part No. Q’ty Remarks
Fuel pipe clamp 2 63D-24367-00 1
Cable clamp 1 63D-48538-00 2
Throttle cable 67G-26301-10 1 895 mm (35 in.)
Shift cable 67G-48321-20 1 965 mm (40 in.)
Grommet 2 68V-42725-10 1
Corrugated tube 6G5-83557-00 1 85 mm (3.3 in.)
Corrugated tube 6K3-83557-00 1 65 mm (2.6 in.)
Stay 6X4-24364-00 1
Ext. bracket 6X4-42121-10 1 92 mm (Long)
10-pin main harness 6X4-82586-20 1 1250 mm (49 in.)
Stud bolt 90116-10175 2 M10-40 mm
Lock nut 90185-10051 4 M10
Corrugated tube 90447-22007 1 230 mm (9.1 in.)
Clamp 90464-09M42 1
Clamp 90465-13M24 5
Clamp 90465-13M30 1
Clip 90468-10005 2
Bolt 97595-06516 2
Protector 6X4-42735-00 1
Steering friction assy 67G-42508-10 1
