Yamaha F20BEH - Page 165

5-47
WIRING DIAGRAMS
GROMMET DESCRIPTION
F75, F80, F90, F100, F115
F150
F200, F225
Throttle cable
Shift cable
Gauge harness
10-pin main harness
Speed tube
Battery cable
Fuel hose
Coolant press. tube or
Coolant temp. lead (OP)
Throttle cable
10-pin main harness
Coolant press. tube (OP)
Coolant temp. lead (OP)
Isolator lead (OP)
Battery cable
Gauge harness
Flushing hose (Market OP)
Shift cable
Speed tube
Fuel hose
10-pin main harness
Gauge harness
Throttle cable
Shift cable
Speed tube
Battery cable
Fuel hose
Coolant press. tube and/or
Coolant temp. lead (OP)
Flushing hose (Market OP)
Isolator cable (OP)
