1-27
OUTBOARD MOTOR DIMENSIONS
OVERALL DIMENSIONS (4-STROKE)
Model
Symbol
F225C
(F225TR)
L-transom
F300AET
(F300TR)
FL300AET
(LF300TR)
F350AET
(F350TR)
FL350AET
(LF350TR)
L1 mm (in.) 664 (26.1) 776 (30.6)
L2 mm (in.) 206 (8.1) 255 (10.0)
L3 mm (in.) — —
L4 mm (in.) 685 (27.0) 732 (28.8)
L5 S mm (in.) — —
L62 (2.4)—
Y——
X — 48 (1.9)
U — 48 (1.9)
L6 S mm (in.) — —
L 1,043 (41.1) —
Y——
X — 1,193 (47.0)
U — 1,310 (51.6)
L7 mm (in.) 615 (24.2) 712 (28.0)
L8 mm (in.) 226 (8.9) 258 (10.2)
L9 S mm (in.) — —
L18 (0.7)—
Y——
X — 56 (2.2)
U — 62 (2.4)
L10 mm (in.) 75 (3.0) 73 (2.9)
H1 S mm (in.) — —
L 951 (37.4) —
Y——
X — 1,098 (43.2)
U — 1,225 (48.2)
H2 mm (in.) 754 (29.7) 909 (35.8)
H3 mm (in.) 216 (8.5) 229 (9.0)
H4 S mm (in.) — —
L 516 (20.3) —
Y——
X — 637 (25.1)
U — 764 (30.1)
H5 mm (in.) — —
H6 S mm (in.) — —
L 779 (30.7) —
Y——
X — 864 (34.0)
U — 941 (37.0)
H7 mm (in.) 399 (15.7) 588 (23.1)
H8 mm (in.) 26 (1.0) 65 (2.6)
H9 mm (in.) 915 (36.0) 1,041 (41.0)
H10 mm (in.) 45 (1.8) 49 (1.9)
H11 S mm (in.) — —
L26 (1.0)—
Y——
X — 26 (1.0)
U — 26 (1.0)
W1 mm (in.) 318 (12.5) 317 (12.5)
W2 mm (in.) — —
W3 mm (in.) — —
W4 mm (in.) — —
W5 mm (in.) 464 (18.3) 476 (18.7)
W6 mm (in.) — —
A1 degree 35 32
A2 degree 67 70
A3 degree 4 3
T1 mm (in.) — 724 (28.5)
