Yamaha F20BEH - Page 87

3-17
REMOTE SWITCH APPLICATIONS
TWIN IG SWITCH
Ref. No. Part No. Description
1
6K1-82570-08 With choke switch
61B-82570-03 W/o choke switch
2 6Y8-82570-02 For Digital network gauge
3 6X6-82570-10 For F350/F300/F250 [Digital Electronic Control], 2nd helm (dual-station)
P
R
B
G
Y
L
Br
W
110 (4.33)
340 (13.39)
R
Y
G
B
145 (5.71) 97 (3.82)
110 (4.33)
128 (5.04)
25.9 (1.02)
54 (2.13)
93 (3.66)
24.25 (0.95)
5.6 (0.22)
66 (2.60)
Cut out shaded areaCut out shaded area
113 (4.45)
25 (0.98)
138 (5.43)
154 (6.06)
50 (1.97)
66 (2.60)
54
(2.13)
5.5 (0.22)
Cut out shaded area
130 (5.12)
109 (4.29)
25 (0.98) 25 (0.98)
126 (4.96)
113 (4.45)
24 (0.94) 24 (0.94)
52.4 (2.06)
5.5 (0.22)
140 (5.51)
86 (3.39)
*110 (4.33)
3.3 (0.13)
*For reference
338 (13.3)
Or
YBr
P
W
B
Cut out shaded areaCut out shaded area
1
2
3
mm (in.)
mm (in.)
mm (in.)
