Maintenance
72
Checkpoints
● Check each of the propeller blades for ero-
sion from cavitation or ventilation, or other
damage.
● Check the propeller shaft for damage.
● Check the splines for wear or damage.
● Check for fish line tangled around the pro-
peller shaft.
● Check the propeller shaft oil seal for dam-
age.
EMU42631
Removing propeller
1. Straighten the cotter pin and pull it out us-
ing a pair of pliers.
2. Remove the propeller nut, washer, and
spacer. WARNING! Do not use your
hand to hold the propeller when loos-
ening the propeller nut.
[EWM01890]
F200C, FL200C, F225B, FL225B, F250A,
FL250A
F225C
3. Remove the propeller, spacer (if
equipped), and thrust washer.
1. Cotter pin
2. Propeller nut
3. Washer
4. Spacer
5. Propeller
6. Thrust washer
1. Cotter pin
2. Propeller nut
3. Washer
4. Spacer
5. Propeller
6. Spacer
7. Thrust washer
4
3
2
1
5
6
ZMU07269
ZMU07547
4
3
2
1
5
6
7
U6P278E0.book Page 72 Monday, April 11, 2011 7:37 PM
