EMU01206
MAIN COMPONENTS
1 Top cowling
2 Cowling lock lever
3 Oil drain bolt
4 Anodes
5 Anti-cavitation plate
6 Trim tab (Anode)
7 Propeller
8 Cooling water inlet
9 Trim angle adjusting rod
0 Clamp bracket
q Tilt support lever
w Flushing device (F50, T50)
e Power trim and tilt switch
r Fuel joint
t Flushing device (F60, T60)
y Remote control box
u Digital tachometer
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
*
*
*
*
*
F60, T60
