Yamaha F50C - Specifications

4-1
E
EMK10111*
SPECIFICATIONS
Model
Unit F50TRC
Item
18 (1.8, 13)
35 (3.5, 25)
18 (1.8, 13)
18 (1.8, 13)
8Spark plug N•m (kgf•m,lb•ft)
8Propeller nut N•m (kgf•m,lb•ft)
8Engine oil drain bolt N•m (kgf•m,lb•ft)
8Engine oil filter N•m (kgf•m,lb•ft)
DIMENSIONS
PERFORMANCE
8Overall Length mm (in.)
8Overall Width mm (in.)
8Overall Height L mm (in.)
8Transom height L mm (in.)
8Weight* L kg (lb.)
718 (28.3)
361 (14.2)
1,397 (55.0)
533 (21.0)
106 (237)
8Full throttle operating range r/min
8Maximum output kW (HP)
8Idling speed (in Neutral) r/min
5,000~6,000
36.8 (50.0) at 5,500 r/min
700~800
ENGINE
8Type
Displacement cm
3
(cu.in.)
Bore × stroke mm (in.)
8Valve clearance (cold engine) IN mm (in)
EX mm (in)
8Ignition system
8Spark plug NGK
Spark plug gap mm (in.)
8Control system
8Starting system
8Battery
Min. cold cranking amps (CCA/SAE) amps at –18°C (–0.4°F)
Min. marine cranking amps (MCA/ABYC) amps at 0°C (32°F)
Min. reserve capacity (RC/SAE) minutes
8Alternator output V-A (W)
8Starting carburetion system
4-stroke, L4
935 (57.1)
63.0 × 75.0 (2.48 × 2.95)
0.15~0.25 (0.006~0.010)
0.25~0.35 (0.010~0.014)
C.D.I system
DPR6EA-9
0.8 ~ 0.9 (0.031~0.035)
Remote control
Electric start
380
502
124
12-10
Prime start system
DRIVE UNIT
8Gear positions
Gear ratio
8Trim/tilt system
8Propeller mark
Forward-Neutral-Reverse
1.85 (24/13)
Power trim & tilt
G
FUEL AND OIL
TIGHTENING TORQUE
8Fuel
Fuel tank capacity L (US gal, Imp gal)
8Recommended engine oil
API
SAE
Engine oil capacity (without oil filter) L (US qt, Imp qt)
Engine oil capacity (with oil filter) L (US qt, Imp qt)
8Recommended gear oil
Gear oil capacity cm
3
(US oz, Imp oz)
Regular unleaded gasoline
(P.O.N.: minimum 86)
—
4-stroke motor oil
SE, SF, SG, SH, SJ
10W-30, 10W-40
2.0 (2.1, 1.8)
2.2 (2.3, 1.9)
Hypoid gear oil (SAE90)
430 (14.5, 15.1)
* Listed weight does not include propeller.
