INSTRUMENT AND CONTROL FUNCTIONS
3-2
1. Turn indicator light “ ”
2. High beam indicator light “ ”
3. Neutral indicator light “N”
Indicator lights
Turn indicator light " "
Neutral indicator light "N"
High beam indicator light " "
The indicator flashes when the turn
switch is moved to the left or right. .
This indicator comes on when the
transmission is in neutral.
This indicator comes on when the
headlight high beam is used.
1. Speedometer
2. Odometer
Speedometer
The speedometer shows riding
speed.
This speedometer is equipped with
an odometer.
1. Tachometer
Tachometer
The Tachometer Indicates Engine
Speed (RPM) and is Pulse Operated.
1
1
2
1
2
3
2
