Yamaha Fazer - Page 56

1. Nut
2. Speedometer Cable
1. Place the Motorcycle on the
centerstand.
2. Loosen the Speedometer cable
Nut '1', & pull the cable '2' out from
the Front Wheel
1. Cotter Pin
2. Axle Nut
3. Remove the cotter pin '1' and axle
nut '2'.
4. Remove the Axle.
5. Remove the wheel, make sure
the Motorcycle is properly
supported.
6. Remove the Front Wheel
PERIODIC MAINTENANCE AND MINOR REPAIR
6-30
1
1
2
2
1
6
