3-7
GB
EMU00211
Engine
●
Check the engine and engine mounting.
●
Look for loose or damaged fasteners.
●
Check the propeller for damage.
●
Check that the battery is in good condition
and battery connections are secure.
EMU01436
CHECKING THE ENGINE OIL LEVEL
1) Put the outboard motor in an upright
position (not tilted).
2) Pull out the oil dipstick and wipe it clean.
3) Completely re-insert the dipstick and
pull out it again.
4) Check the oil level using the dipstick to
be sure the level falls between the upper
and lower marks. Fill with oil if it is below
the lower mark, or drain to the specified
level if it is above the upper mark.
1
Oil dipstick
2
Lower level mark
3
Upper level mark
EMU01031
FILLING FUEL
1) Remove the fuel tank cap.
2) Fill the fuel tank carefully.
3) Close the cap securely after refueling.
Wipe up any spilled fuel.
U69J73A0.book Page 7 Monday, March 31, 2003 2:44 PM
