3-23
GB
ADJUSTING TRIM ANGLE
EMU01657
Power Trim/Tilt Model
WARNING
@
●
Be sure all people are clear of the out-
board motor when adjusting the
trim/tilt angle, also be careful not to
pinch any body parts between the
drive unit and clamp bracket.
●
Use caution when trying a trim posi-
tion for the first time. Increase speed
gradually and watch for any signs of
instability or control problems.
●
Use the power trim/tilt switch located
on the bottom engine cowling (if
equipped) only when the boat is at a
complete stop with the engine off.
@
The outboard motor trim angle can be
adjusted operating the power trim/tilt switch
1
.
To raise the bow (“trim-out”), push the switch
UP.
To lower the bow (“trim-in”), push the switch
DN.
Make test runs with the trim set to different
angles to find the position that works best for
your boat and operating conditions.
NOTE:
@
To adjust the trim angle while the boat is
moving, use the power trim and tilt switch
located on the remote control box.
@
U69J73A0.book Page 23 Monday, March 31, 2003 2:44 PM
