Basic components
13
EMU25797
Main components
NOTE:
* May not be exactly as shown; also may not be included as standard equipment on all models.
F6, F8
1. Top cowling
2. Top cowling lock lever
3. Anti-cavitation plate
4. Propeller*
5. Cooling water inlet
6. Drain screw
7. Trim rod
8. Clamp bracket
9. Manual starter handle
10.Warning indicator
11.Engine stop button/Engine stop lanyard
switch
12.Gear shift lever
13.Tiller handle
14.Steering friction lever
15.Tilt lock lever
16.Clamp screw
17.Rope attachment
18.Flushing device
19.Choke knob
U60R13E0.book Page 13 Thursday, April 6, 2006 10:29 AM
