Yamaha KX-E300 - Controls and Display; Front Panel Controls; Display Indicators

2
NAMES OF BUTTONS AND CONTROLS
1 Tape tray (P.5)
2 (Open / Close) (P.5)
3 & (Stop) (P.5)
4 # (Play) (P.5)
5 STANDBY/ON (P.5)
6 COUNTER RESET (P.6)
7 MODE (P.5)
8 Multi-information display (P.2)
9 REC/PAUSE (P.6)
0 DOLBY NR (P.1)
q DIRECTION @# (P.5)
w ! / ⁄ (Rewind, Music search
backward/Fast-forward, Music search
forward) (P.5)
e REC LEVEL (P.6)
Display
1 Counter display
2 Reverse mode indicator
3 Dolby Noise Reduction indicator
4 Direction indicator
5 REC indicator
6 Music SEARCH indicator
7 PLAY indicator
8 Rewind/Fast-forward indicator
9 REC/PLAY level indicator
STANDBY/ON
NATURAL SOUND STEREO CASETTE DECK KX-E300
REC LEVEL
MIN MAX
DOLBY
NR
MODE
COUNTER
RESET
DIRECTION
REC/
PAUSE
DOLBY B-C NR
6 7598 0 we
1234
q
– 30 20 15 10 8 6 4 2 0 2 4 6 +dB
L
R
SEARCH
BC
REC PLAY
23 4 56 7 8
9
1
Front panel
