MIDI Data Format
Appendix
66 1 PEG RATE1 PR1
67 1 PEG RATE2 PR2
68 1 PEG RATE3 PR3
69 1 PEG RATE4 PR4
6A 1 PEG LEVEL1 PL1
6B 1 PEG LEVEL2 PL2
6C 1 PEG LEVEL3 PL3
6D 1 PEG LEVEL4 PL4
6E 1 ALGORITHM SELECTOR -- ALS
6F 1 OSC PHASE INIT / FEEDBACK LEVEL -- OPI FBL
70 1 LFO SPEED LFS
71 1 LFO DELAY TIME LFD
72 1 PITCH MODULATION DEPTH LPMD
73 1 AMPLITUDE MODULATION DEPTH LAMD
74 1 LFO PITCH MODULATION SENSITIVITY / LFO WAVE / LFO KEY SYNC LPMS LFW LFKS
75 1 TRANSPOSE TRNP
76 1 VOICE NAME VNAM1
77 1 VOICE NAME VNAM2
78 1 VOICE NAME VNAM3
79 1 VOICE NAME VNAM4
7A 1 VOICE NAME VNAM5
7B 1 VOICE NAME VNAM6
7C 1 VOICE NAME VNAM7
7D 1 VOICE NAME VNAM8
7E 1 VOICE NAME VNAM9
7F 1 VOICE NAME VNAM10
TOTAL SIZE 1000 (80h X 20h = 1000h)
<3-3>
DX Packed Voice Additional Parameter - AMEM format
Parameter# Size Parameter Description
(H) (H) BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
00 1 NOT USED --
01 1 AMPLITUDE MODULATION SENSITIVITY -- OP5 OP6
02 1 AMPLITUDE MODULATION SENSITIVITY -- OP3 OP4
03 1 AMPLITUDE MODULATION SENSITIVITY -- OP1 OP2
04 1 RANDOM PITCH / PEG VELOCITY SW / LFO KEY TRIGGER / PEG RANGE RNDP VPSW LTRG PEGR
05 1 PITCH BEND RANGE / POLY/MONO,UNISON SWITCH -- PBR PMOD
06 1 PITCH BEND STEP -- PBS
07 1 PORTAMENTO STEP / PORTAMENTO MODE -- PQNT PORM
08 1 PORTAMENTO TIME POS
09 1 NOT USED --
0A 1 NOT USED --
0B 1 NOT USED --
0C 1 NOT USED --
0D 1 NOT USED --
0E 1 NOT USED --
0F 1 NOT USED --
10 1 NOT USED --
11 1 NOT USED --
12 1 NOT USED --
13 1 NOT USED --
14 1 NOT USED --
15 1 NOT USED --
16 1 NOT USED --
17 1 NOT USED --
18 1 PITCH EG RATE SCALING DEPTH -- PGRS
19 1 NOT USED --
1A 1 NOT USED --
1B 1 NOT USED --
1C 1 NOT USED --
1D 1 NOT USED --
1E 1 NOT USED --
1F 1 NOT USED --
20 1 NOT USED --
21 1 NOT USED --
22 1 UNISON DETUNE DEPTH -- UDTN
TOTAL SIZE 460 (23h X 20h = 460h)
