MIDI Data Format
138
Appendix
<4-1>
Rhythm Track Parameter Base Address
MODEL ID = 6D
<4-2>
MIDI Parameter Change table ( SYSTEM1 )
Address Size Data Parameter Description Default
(H) (H) (H) (H)
00 00 00 1 00-0F,7F SYNTH Rcv Ch 1...16,OFF 0
01 1 00-0F,7F RHYTHM1 Rcv Ch 1...16,OFF 1
02 1 00-0F,7F RHYTHM2 Rcv Ch 1...16,OFF 2
03 1 00-0F,7F RHYTHM3 Rcv Ch 1...16,OFF 3
04 1 (RESERVED) --
05 (NOT USED) --
06 1 (RESERVED) --
07 2 01...C8 Play Effect Gate Time 1%(1)...200%(C8) 64(100%)
09 1 00...03 Step Seq Loop Type forward(0),backward(1),alternateA(2), alternateB(3) 00(forward)
TOTAL SIZE 09
<4-3>
MIDI Parameter Change table (CURRENT EFFECT)
Address Size Data Parameter Description Default
(H) (H) (H) (H)
02 01 00 1 00 - 03 EFFECT TYPE MSB refer to Effect Type List 00
01 1 00 - 02 EFFECT TYPE LSB refer to Effect Type List 00
02 1 00 - 7F EFFECT PARAMETER refer to Effect Type List 00
TOTAL SIZE 3
Parameter Address Description
(H) (M) (L)
System 00 00 00 System1
Current Effects 02 01 00 Cuttnet Effect
Current Multi Part 08
:
00
:
02
08
00
:
00
00
Rhythm Track 1 Part Parameter
:
Rhythm Track 3 Part Parameter
Synth Track Part Parameter
Current Rhythm StepSeq 10
:
00
:
02
00
:
00
Current Rhythm Trk1 Step Seq
:
Current Rhythm Trk3 Step Seq
User Pattern Rhythm Step Seq 20
:
00
:
7f
00
:
00
User Pattern Rhythm Trk1 Step Seq 1
:
User Pattern Rhythm Trk1 Step Seq 128
21
:
00
:
7f
00
:
00
User Pattern Rhythm Trk2 Step Seq 1
:
User Pattern Rhythm Trk2 Step Seq 128
22
:
00
:
7f
00
:
00
User Pattern Rhythm Trk3 Step Seq 1
:
User Pattern Rhythm Trk3 Step Seq 128
User Pattern Effect 30
:
00
:
7f
00
:
00
User Pattern Effect 1
:
User Pattern Effect 128
User Pattern Multi Part 40
:
00
:
7f
00
:
00
Rhythm Trk 1 User Pattern Part 1
:
Rhythm Trk 1 User Pattern Part 128
41
:
00
:
7f
00
:
00
Rhythm Trk 2 User Pattern Part 1
:
Rhythm Trk 2 User Pattern Part 128
42
:
00
:
7f
00
:
00
Rhythm Trk 3 User Pattern Part 1
:
Rhythm Trk 3 User Pattern Part 128
48
:
00
:
7f
00
:
00
Synth Track User Pattern Part 1
:
Synth Track User Pattern Part 128
User Song 60
:
00
:
7f
00
:
00
Song1 measure1
:
Song1 measure128
::: :
69
:
00
:
7f
00
:
00
Song10 measure1
:
Song10 measure128
70
:
00
:
7f
00
:
00
Song1 measure129
:
Song1 measure256
::: :
79
:
00
:
7f
00
:
00
Song10 measure129
:
Song10 measure256
