ELEC
7-22
LIGHTING SYSTEM
TROUBLESHOOTING
THE HEADLIGHT, HEADLIGHT
INDICATOR, POSITION LIGHT, METER
LIGHT, LICENSE LIGHT AND/OR
TAILLIGHT DO NOT WORK
Procedure
Check:
1. "LIGHTS" switch
2. Lighting coil resistance
3. "HI/LO" switch
4. Connections
NOTE:
• Remove the following parts before proceed-
ing with the troubleshooting:
1) Side covers
2) Handlebar covers
3) Front panel
• For accurate troubleshooting use the fol-
lowing special tools.
Pocket tester:
90890-03112
To Next Page
