Yamaha MDX-596 Service Manual

MDX-596
MDX-596
Description of TEST modes
1. EJECT mode To TEMP setting (of EEPROM setting)
[ _ _ EJECT _ _ _ ] To CONTROL setting (of EEPROM setting)
Laser power setting (record/reproduction power) is performed.
2. AUTO preliminary adjustment mode Automatic preliminary adjustment is performed.
[ _ AUT _ YOBI _ ] Adjusted values are output by using the interface.
3. AUTO adjustment mode Automatic adjustment is performed. (Grating adjustment mode after this adjustment.)
[ AUTO _ AJST _ ] Adjusted values are output by using the interface.
Continuous reproduction is performed. (Error rate on display, jump test)
4. AUTO AFB adjustment mode Automatic focus balance adjustment is performed.
[ _ AUT _ AFB _ _ ] Adjusted values are output by using the interface.
RESULT preparation mode Not used (Do not use this function as it is not for servicing)
[ _ RST _ YOBI _ ]
RESULT mode (main adjustment) Not used (Do not use this function as it is not for servicing)
[ _ RESULT _ _ _ ]
MANUAL preliminary adjustment mode Not used (Do not use this function as it is not for servicing)
[ _ MNU _ YOBI _ ]
MANUAL adjustment mode Not used (Do not use this function as it is not for servicing)
[ _ MNU _ AJST _ ]
5. EEPROM setting mode Various factors of the digital servo function are changed manually.
[ EEPROM _ SET ] The voltage is measured at the temperature detect terminal and the standard value is set.
6. TEST-PLAY mode Continuous reproduction from the specified address is performed.
[ TEST _ PLAY _ ] C1 error rate is measured and ADIP error rate is measured.
7. TEST-REC mode Continuous recording from the specified address is performed.
[ TEST _ REC _ _ ]
8. INNER mode The position where the INNER switch is turned ON is measured.
[ _ _ INNER _ _ _ ]
9
1. EJECT mode
Step Setting method Remark Display
1
2
3
4
5
6
7
8
EJECT status in the TEST mode
Press the INPUT button.
Press the INPUT button.
Press the INPUT button.
Press the TITLE edit button.
Press the CHARA. button.
Press the DISPLAY button.
Press the DELETE/CANCEL button.
EJECT menu (No disc is loaded.)
Reproduction power output status
Recording power output status
Since this mode is not required for servicing , proceed to another mode promptly.
To TEMP setting
(Refer to TEMP setting)
To CONTROL1 setting
To CONTROL2 setting
EJECT menu
[ _ _ EJECT _ _ _ ]
[ ppw _ _ _ _ _ _ _ ]
[ rpw _ _ _ _ _ _ _ ]
[ xpw _ _ _ _ _ _ _ ]
[ TEMP _❍ ❍ _◆ ◆]
[ CONTROL1 _ 08 ]
[ CONTROL2 _ 02 ]
[ _ _ EJECT _ _ _ ]
