MDX-596
MDX-596
8
3. How to cancel test mode (Entry of EEPROM adjustment value)
1) Be sure to perform AUTO preliminary adjustment, AUTO adjustment and AUTO AFB adjustment.
( “COMPLETE” appears on the display)
2) After completing above ajustments, press the REC button. (Entry to EEPROM initiates then.)
The TEST mode is completed. ( “Test End” appears on the display)
3) Press the EJECT button to take out the disc.
4) Turn off the power.
2. How to set to each mode
Every time the DISPLAY (forward) or EDIT (reverse) button is pressed, the mode changes. (For operation of each
mode, refer to the section describing each mode.)
Since this mode is not required for servic-
ing , proceed to another mode promptly.
*
AUTO_AJST (AUTO adjustment)
@
AUT_AFB (AUTO AFB adjustment)
@
RST_YOBI (RESULT preparation)
@
RESULT (RESULT)
@
MNU_YOBI (MANUAL preliminary adjustment)
@
MNU_AJST (MANUAL adjustment)
@
EEPROM_SET (EEPROM setting)
@
AUT_YOBI (AUTO preliminary adjustment)
@
Panel key Function
Command code
REC TEST mode end (entry of EEPROM) 1FH
EJECT Eject B3H
DISPLAY Menu feeding in TEST mode (1) / (Feeding of menus mainly related to adjustment and EEPROM) B2H
TITLE
Menu feeding in TEST mode (2) / (Feeding of menus mainly related to continuous playback and continuous recording)
B4H
CHARA.
Menu feeding in TEST mode (3) (Feeding of menus mainly related to INNER mode and JUMP SELECT)
F2H
EDIT Menu feeding in reverse in TEST mode (Menu feeding in reverse in each TEST mode) A8H
SET/ENTER Finalization of menu selection or starting of its execution A2H
DELETE/CANCEL Stopping each test item and shifting to menu selection at one step upper level A7H
SEARCH w Forced feeding of the slide (in FWD direction) / Execution of JUMP function (FWD) AAH
ADDRESS setting value increased / Specification of direction when setting the tracking
SEARCH e Forced feeding of the slide (in REV direction) / Execution of JUMP function (REV) ACH
ADDRESS setting value reduced / Specification of direction when setting the tracking
JOG DIAL y Forced feeding of the disc to EJECT / setting value increased F3H
JOG DIAL t Forced feeding of the disc to LOAD / setting value reduced F4H
INPUT
Switching of laser power at EJECT / switching of display for continuous playback / switching of digit setting when setting ADDRESS
F5H
RANDOM –
REPEAT S/F –
REPEAT A-B –
SCROLL –
PLAY/PAUSE –
STOP –
● Panel keys used in TEST mode
