MOXF6/MOXF8 Reference Manual
File Mode
[F1] CONFIG
[F2] SAVE
[F3] LOAD
[F4] RENAME
[F5] DELETE
[F6] FLASH
Supplementary Information
154
next highest level (directory A). Next, go up one more level (to the root directory). Now that both A and B are available,
open directory B. In this way you can move up or down as desired through the folder hierarchy.
Path
The location of the directories (folders) and files currently indicated at the “Dir” line on the display is referred to as a
“path.” This indicates the current directory, which device it belongs to, and in which folder(s) it is contained. “Directory
C” illustrated above is described as path “USB_HDD/A/C.”
Mount
Refers to the operation that enables an external memory device for use with the instrument. A USB flash memory device
is automatically mounted as soon as it is connected to the USB [TO DEVICE] terminal on the rear panel of the MOXF6/
MOXF8. The reverse procedure (removing) is called “Unmount.”
Format
The operation of initializing a storage device (such as a hard disk) is referred to as “format.” The format operation erases
all data from the target memory device and is irreversible.
Save/Load
“Save” means that the data created on the MOXF6/MOXF8 is saved to the USB flash memory as a file, while “Store”
means that the data created on the MOXF6/MOXF8 is stored to internal memory. “Load” means that the file on the USB
flash memory is loaded to internal memory.
[SF1] CURRENT
Indicates the currently recognized flash memory device.
USB Device
Status Free
Indicates the amount of free capacity for the currently recognized USB flash memory device.
Status Total
Indicates the amount of total memory for the currently recognized USB flash memory device.
Expansion Module
Unmounted
Unformatted
Formatted
Indicates the status for the currently recognized Flash memory expansion module (optional).
Status Free
Indicates the amount of free memory capacity for the currently recognized Flash memory expansion module
(optional).
Status Total
Indicates the amount of total memory for the currently recognized Flash memory expansion module (optional).
[SF2] FORMAT
Formats the USB flash memory device connected to the instrument. Before you can use a new USB flash memory
device with the MOXF6/MOXF8, you will need to format it. For instructions on formatting, see page 161.
Volume Label
Determines the name of the Volume Label. The name can contain up to eleven characters, and is entered by using the
[DATA] dial and cursor [<]/[>] buttons. Pressing the [SF6] button calls up the character list for entering the name. For
detailed instructions on naming, see the “Basic Operation” of the Owner’s Manual.
Free
Indicates the amount of free/total memory for the currently recognized USB flash memory device.
[F1] CONFIG (Configuration)

Yamaha MOXF8 Specifications

General

Product type	Digital synthesizer
Product color	Black
Sound effects	Chorus, Reverberation
Tap tempo switch	Yes
Chorus effects quantity	22
Keyboard number of keys	88
Maximum polyphony (notes)	124
Reverberation effects quantity	9
Power source type	DC
Display type	LCD
Headphone outputs	1

Weight and Dimensions

Depth	405 mm
Width	1320 mm
Height	168 mm
Weight	14900 g
