Yamaha MT09 - Bulb Wattage and Fuse Information

Specifications
8-3
1
2
3
4
5
6
7
8
9
10
11
12
Bulb wattage  quantity:
Headlight:
H4, 60.0 W/55.0 W x 1
Brake/tail light:
LED
Front turn signal light:
10.0 W  2
Rear turn signal light:
10.0 W  2
Auxiliary light:
5.0 W  2
License plate light:
5.0 W  1
Meter lighting:
LED
Neutral indicator light:
LED
High beam indicator light:
LED
Oil level warning light:
LED
Turn signal indicator light:
LED
Coolant temperature warning light:
LED
Engine trouble warning light:
LED
ABS warning light:
LED (MT09A)
Immobilizer system indicator light:
LED
Traction control system indicator/warning
light:
LED (MT09A)
Fuse(s):
Main fuse:
50.0 A
Auxiliary fuse:
2.0 A
Headlight fuse:
15.0 A
Signaling system fuse:
7.5 A
Ignition fuse:
15.0 A
Parking lighting fuse:
7.5 A
Radiator fan motor fuse:
15.0 A
Fuel injection system fuse:
10.0 A
ABS control unit fuse:
7.5 A (MT09A)
ABS motor fuse:
30.0 A (MT09A)
ABS solenoid fuse:
15.0 A (MT09A)
Backup fuse:
7.5 A
Electronic throttle valve fuse:
7.5 A
