Yamaha MT09 - Right View Component Identification

Description
2-2
1
2
3
4
5
6
7
8
9
10
11
12
EAU10421
Right view
21 3 4
678910 5
1. Fuel tank cap (page 3-22)
2. Front fork rebound damping force adjusting screw (page 3-26)
3. Headlight (page 6-34)
4. Fuse box 1 (page 6-31)
5. Coolant reservoir (page 6-11)
6. Engine oil level check window (page 6-9)
7. Engine oil filler cap (page 6-9)
8. Brake pedal (page 3-19)
9. Rear brake light switch (page 6-20)
10.Rear brake fluid reservoir (page 6-21)
