Yamaha PSR-S650 Service Manual

PSR-S650
4
Function
Registration Registration Memory 8 buttons (x 8 Banks) with Freeze function
Demo Demonstration Yes
Overall Controls
Metronome Yes
Tempo Range 5–280
Transpose -12 – 0 – +12
Tuning 415.3–466.2Hz
Octave buttons Yes
Scale Yes
Expansion Pack Installation Yes
Storage and
Connectivity
Internal Memory 1,130 KB
External Drives Optional USB fl ash Memory (via USB TO DEVICE)
Connectivity
USB TO HOST, USB TO DEVICE, DC IN 16V,
PHONES/OUTPUT, SUSTAIN
Amplifi ers and
Speakers
Amplifi ers 12W + 12W
Speakers 12cm x 2 + 3cm x 2
Power Supply
Power Supply Adaptor: PA-300 or an equivalent recommended by Yamaha
Power Consumption 25 W (When using PA-300 power adaptor)
Auto Power Off Function Yes
Included Accessories
• Owner’s Manual
• Data List
• Music Rest
• My Yamaha Product User Registration
• AC Power adaptor
(*PA-300 or an equivalent recommended by Yamaha)
* May not be included depending on your particular area.
Optional Accessories
• Adaptor: PA-300 or an equivalent recommended by Yamaha
• Footswitch: FC4/FC5
• Keyboard Stand: L-6/L-7
• Headphones: HPE-150/HPE-30

Yamaha PSR-S650 Specifications

General

Product color	Black
Sound effects	Chorus, Flanger/Digital Signal Processing (DSP), Reverberation
Pitch bend wheel	Yes
Maximum polyphony (notes)	64
Control type	Buttons, Rotary, Scrollbar, Touch
MIDI-keyboard number of keys	61 keys
Display type	LCD
Interface	USB
Headphone outputs	1
Input voltage	16 V
Power source type	DC
Power consumption (typical)	25 W

Weight and Dimensions

Depth	405 mm
Width	946 mm
Height	137 mm
Weight	7300 g
