PSR-S650
8
PANEL LAYOUT(パネルレイアウト)
Front Panel
q [ ] (Standby/On) switch
w [MASTER VOLUME] control
e [DEMO] button
r [SONG MODE] button
t SONG buttons
y [USB] button
u [REC] button
i STYLE category selection buttons
o STYLE CONTROL buttons
!0 SONG CONTROL buttons
!1 TRANSPOSE buttons
!2 METRONOME button
!3 TEMPO buttons
!4 REGISTRATION MEMORY-related buttons
!5 REGISTRATION MEMORY/Track buttons
!6 Display and related controls
!7 [MDB] button
!8 [FILE MENU] button
!9 [FUNCTION] button
@0 ONE TOUCH SETTING buttons
フロントパネル
q [ ](電源切/入)スイッチ
w [全体音量](MASTERVOLUME)コントロール
e [デモ](DEMO)ボタン
r [ソングモード](SONGMODE)ボタン
t ソングボタン群
y [USB]ボタン
u [録音](REC)ボタン
i スタイルボタン群
o スタイルコントロールボタン群
!0 ソングコントロールボタン群
!1 トランスポーズボタン
!2 [メトロノーム](METRONOME)ボタン
!3 テンポボタン群
!4 レジストレーションメモリー関連ボタン群
!5 レジストレーションメモリー /ソングトラック/
スタイルトラックボタン群
!6 画面と操作ボタン群
!7 [ミュージックデータベース](MDB)ボタン
!8 [ファイル操作](FILEMENU)ボタン
!9 [機能](FUNCTION)ボタン
@0 ワンタッチセッティング(OTS)ボタン[1] [4]
/
4
)
1 *





-


6
0
2

A
A’
Flont Panel
