Yamaha PSR-S650 Service Manual

9
PSR-S650
@1 VOICE category selection buttons
@2 VOICE CONTROL buttons
@3 UPPER OCTAVE buttons
@4 PITCH BEND wheel
■ Rear Panel
@5 CONTRAST knob
@6 [USB TO HOST] terminal
@7 [USB TO DEVICE] terminal
@8 [SUSTAIN] jack
@9 [PHONES/OUTPUT] jack
#0 [DC IN] jack
@1 楽器(VOICE)ボタン群
@2 ボイスコントロールボタン群
@3 オクターブ(UPPEROCTAVE)ボタン
@4 ピッチベンドホイール
■リアパネル
@5 CONTRASTつまみ
@6 [USBTOHOST]端子
@7 [USBTODEVICE]端子
@8 [SUSTAIN]端子
@9 [PHONES/OUTPUT]端子
#0 [DCIN16V]端子


     



 


A
A’
Rear Panel

Yamaha PSR-S650 Specifications

General

Product color	Black
Sound effects	Chorus, Flanger/Digital Signal Processing (DSP), Reverberation
Pitch bend wheel	Yes
Maximum polyphony (notes)	64
Control type	Buttons, Rotary, Scrollbar, Touch
MIDI-keyboard number of keys	61 keys
Display type	LCD
Interface	USB
Headphone outputs	1
Input voltage	16 V
Power source type	DC
Power consumption (typical)	25 W

Weight and Dimensions

Depth	405 mm
Width	946 mm
Height	137 mm
Weight	7300 g
