Yamaha PSR-S650 Service Manual

3
PSR-S650
SPECIFICATIONS
Size/Weight
Dimensions W x D x H 946 x 405 x 137 mm (37-1/4" x 15-15/16" x 5-3/8")
Weight 7.3Kg (16 lbs. 1 oz.)
Keyboard
Number of Keys 61
Touch Response Yes
Display
Type 320 x 240 dots QVGA B/W 4.3 inch display
Contrast Yes
Score Display Function Yes
Lyric Display Function Yes
Language English/Japanese
Controller Pitch Bend Wheel Yes
Panel Language English
Voices
Tone Generation
Tone Generating
Technology
AWM Stereo Sampling
Polyphony
Number of Polyphony
(Max.)
64
Preset
Number of Voices
357 + 28 Drum/SFX Kits + 480 XG + GM2 (for GM2 Song
playback) + GS (for GS Song playback)
Mega Voices 9
Live! Voices 18
Cool! Voices 22
Sweet! Voices 12
Voice Expansion
Voice Yes
Wave Yes (16MB Flash ROM)
Voice Set Yes
Compatibility XG, XF, GS, GM, GM2
Effects
Types
Reverb 35
Chorus 44
DSP 237
Master EQ 5
Harmony 26
Function
Dual Yes
Split Yes
Panel Sustain Yes
Accompaniment
Styles
Preset
Number of Preset Styles 181
Fingering Multi fi nger, FullKeyboard, AI Fingered
Style Control Intro x 3, Ending x 3, Main x 4, Fill In x 4
Compatibility SFF GE
Custom
User Styles Yes
Style Creator Yes
Other Features
Music Database 784 + External Files
OTS (One Touch Setting) 4 for Each Style
Song
Preset Number of Preset Songs 9
Custom
User Songs Yes
Song Edit Yes
Recording
Number of Songs 5
Tracks 16
Data Capacity Approx. 30,000 notes (when only “melody” tracks are recorded)
Recording Function Quick Recording, Multi Recording, Song Editing
Compatible Data
Format
Playback SMF (Format 0 & 1), XF
Recording SMF (Format 0)

Yamaha PSR-S650 Specifications

General

Product color	Black
Sound effects	Chorus, Flanger/Digital Signal Processing (DSP), Reverberation
Pitch bend wheel	Yes
Maximum polyphony (notes)	64
Control type	Buttons, Rotary, Scrollbar, Touch
MIDI-keyboard number of keys	61 keys
Display type	LCD
Interface	USB
Headphone outputs	1
Input voltage	16 V
Power source type	DC
Power consumption (typical)	25 W

Weight and Dimensions

Depth	405 mm
Width	946 mm
Height	137 mm
Weight	7300 g
