Yamaha PSR-S650 Reference

PSR-S650 MIDI Reference
2
MIDI Data Format / MIDI-Datenformat / Format des données MIDI /
Formato de datos MIDI
CHANNEL MESSAGE/REALTIME MESSAGE
: Transmitted/received.
: Transmitted when playing a song or style which contains MIDI Events.
: Not transmitted/received.
MIDI Events
Status byte 1st Data byte 2nd Data byte
Trans-
mitted
Recep-
tion
Status Data (HEX) Parameter Data (HEX) Parameter
Key Off 8nH (n: channel no.) kk Key no. (0-127) vv Velocity (0-127)  
Key On 9nH kk Key no. (0-127) vv Key On: vv=1-127
Key Off: vv=0

Control Change BnH 0 (00H) Bank Select MSB 0
8
62
63
64
104
120
121
126
127
(00H)
(08H)
(3EH)
(3FH)
(40H)
(68H)
(78H)
(79H)
(7EH)
(7FH)
Normal
Mega Voices
ExpansionPack
(Drums/Percussion Kit)
ExpansionPack
(Normal)
SFX Voices
Normal
GM2 Rhythm
GM2 Normal
SFX Kit
Drum Kit

32 (20H) Bank Select LSB 0-127 
1 (01H) Modulation 0-127 (00H...7FH)  
5 (05H) Portamento Time 0-127 (00H...7FH)  
6 (06H) Data Entry MSB 0-127 (00H...7FH) 
38 (26H) Data Entry LSB 0-127 (00H...7FH)  
7 (07H) Main Volume 0-127 (00H...7FH) 
10 (0AH) Panpot 0-127 (00H...7FH) 
11 (0BH) Expression 0-127 (00H...7FH)  
64 (40H) Damper (Sustain) 0-127 (00H...7FH) 
65 (41H) Portamento Switch 0-127 (00H...7FH)  
66 (42H) Sostenuto 0-127 (00H...7FH)  
67 (43H) Soft Pedal 0-127 (00H...7FH)  
71 (47H) Harmonic Content 0-127 (00H...7FH)  
72 (48H) Release Time 0-127 (00H...7FH) 
73 (49H) Attack Time 0-127 (00H...7FH)  
74 (4AH) Brightness 0-127 (00H...7FH)  
75 (4BH) Decay Time 0-127 (00H...7FH)  
76 (4CH) Vibrato Rate 0-127 (00H...7FH)  
77 (4DH) Vibrato Depth 0-127 (00H...7FH)  
78 (4EH) Vibrato Delay 0-127 (00H...7FH)  
84 (54H) Portamento Control 0-127 (00H...7FH)  
91 (5BH) Effect1 Depth
(Reverb Send Level)
0-127 (00H...7FH) 
93 (5DH) Effect3 Depth
(Chorus Send Level)
0-127 (00H...7FH) 
94 (5EH) Effect4 Depth
(Variation Send Level)
0-127 (00H...7FH) 
96 (60H) Increment 0-127 (00H...7FH)
 
97 (61H) Decrement 0-127 (00H...7FH)  
98 (62H) NRPN LSB 0-127 (00H...7FH)  
99 (63H) NRPN MSB 0-127 (00H...7FH)
100 (64H) RPN LSB 0-127 (00H...7FH) 
101 (65H) RPN MSB 0-127 (00H...7FH)
Mode Message BnH 120 (78H) All sound off 0  
121 (79H) Reset all controller 0  
122 (7AH) Local control 0-3F: OFF
40-7F: ON
 
123 (7BH) All note off 0  
124 (7CH) OMNI OFF (*1) 0  
125 (7DH) OMNI ON 0  
126 (7EH) MONO (*2) 0-16 (00H...10H)  
127 (7FH) POLY (*3) 0  
Supplementary Information
The Multi-timbre and Poly modes are always active. No change occurs when Omni on, Omni off mode messages are received.
*1 Same operation as when receiving All Note Off.
*2 Same operation as when receiving All Sound Off.
*3 Same operation as when receiving All Sound Off.
Program Change CnH pp Voice Number - - 
Channel After Touch DnH vv -  
Polyphonic After Tch AnH kk vv  
Pitch Bend Change EnH cc LSB dd MSB 
RealTime Message F8H MIDI Clock - - 
FAH Star t - - 
FCH Stop - - 
FEH Active Sens - - 
