Yamaha PSR-S650 Reference

MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
PSR-S650 MIDI Reference
7
SYSTEM EXCLUSIVE MESSAGE
MIDI Event Data Format
Trans-
mitted
Recep-
tion
Universal System Exclusive
MIDI Master Volume F0H 7FH 7FH 04H 01H ll mm F7H
ll mm Volume (mm = MSB, ll = LSB)
or
F0H 7FH XN 04H 01H ll mm F7H
XN When N is received N=0-F, whichever is received.
X = Don’t Care
ll mm Volume (mm = MSB, ll = LSB)
 
GM System On F0H 7EH 7FH 09H 01H F7H
or
F0H 7EH XN 09H 01H F7H
0xxxnnnn XN When N is received N=0-F, whichever is received.
X = Don’t care.

Master Fine Tuning
[GM2]
F0 7F XN 04 03 SS TT F7
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F, whichever is received. X=ignored
00000100 04 = Sub-ID #1=Device Control Message
00000011 03 = Sub-ID #2=Master Fine Tuning
0sssssss SS = Fine Tuning LSB
0ttttttt TT = Fine Tuning MSB
11110111 F7 = End of Exclusive
 
Master Coarse Tuning
[GM2]
F0 7F XN 04 04 00 TT F7
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F, whichever is received. X=ignored
00000100 04 = Sub-ID #1=Device Control Message
00000100 04 = Sub-ID #2=Master Coarse Tuning
00000000 00
0ttttttt TT = Coarse Tuning MSB
11110111 F7 = End of Exclusive
 
Reverb Parameter
[GM2]
F0 7F XN 04 05 01 01 01 01 01 PP VV ... F7
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F, whichever is received. X=ignored
00000100 04 = Sub-ID #1=Device Control Message
00000101 05 = Sub-ID #2=Global Parameter Control
00000001 01 = Slot path length = 1
00000001 01 = Parameter ID width = 1
00000001 01 = Value width = 1
00000001 01 = Slot path MSB = 1
00000001 01 = Slot path LSB = 1 (Reverb)
0ppppppp PP = Parameter to be controlled.
0vvvvvvv VV = Value for the Parameter.
... ...
11110111 F7 = End of Exclusive
 
Chorus Parameter
[GM2]
F0 7F XN 04 05 01 01 01 01 02 PP VV ... F7
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F, whichever is received. X=ignored
00000100 04 = Sub-ID #1=Device Control Message
00000101 05 = Sub-ID #2=Global Parameter Control
00000001 01 = Slot path length = 1
00000001 01 = Parameter ID width = 1
00000001 01 = Value width = 1
00000001 01 = Slot path MSB = 1
00000010 02 = Slot path LSB = 2 (Chorus)
0ppppppp PP = Parameter to be controlled.
0vvvvvvv VV = Value for the Parameter.
... ...
11110111 F7 = End of Exclusive
 
Channel Pressure
(Aftertouch)
[GM2]
F0 7F XN 09 01 0M PP RR ... F7
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F, whichever is received. X=ignored
00001001 09 = Sub-ID #1=Controller Destination Setting
00000001 01 = Sub-ID #2=Controller Type: 01 (Channel Pressure)
0000mmmm 0M = MIDI Channel (00-0F)
0ppppppp PP = Controlled Parameter
0rrrrrrr RR = Data
... ...
11110111 F7 = End of Exclusive
Make sure to set both the controlled parameter and the range.
Parameters not set will be restored to their default values.
Control Parameter (pp) Data (RR) Description Default Value
----------------------------------------------------------------------------------------------------------------------------
pp=00 Pitch Control 28H-58H -24...0...+24semitones 40H
pp=01 Filter Cutoff Control 00H-7FH -9600...0...+9450cents 40H
pp=02 Amplitude Control 00H-7FH -100...0...+100% 40H
pp=03 LFO Pitch Depth 00H-7FH 0...127 00H
pp=04 LFO Filter Depth 00H-7FH 0...127 00H
pp=05 LFO Amplitude Depth 00H-7FH 0...127 00H
 

Yamaha PSR-S650 Specifications

General

Product color	Black
Sound effects	Chorus, Flanger/Digital Signal Processing (DSP), Reverberation
Pitch bend wheel	Yes
Maximum polyphony (notes)	64
Control type	Buttons, Rotary, Scrollbar, Touch
MIDI-keyboard number of keys	61 keys
Display type	LCD
Interface	USB
Headphone outputs	1
Input voltage	16 V
Power source type	DC
Power consumption (typical)	25 W

Weight and Dimensions

Depth	405 mm
Width	946 mm
Height	137 mm
Weight	7300 g
