Yamaha R-S201 User Manual

1 En
PREPARATIONINTRODUCTION
BASIC
OPERATION
ADDITIONAL
INFORMATION
ADVANCED
OPERATION
English
USEFUL FEATURES ............................................ 1
SUPPLIED ACCESSORIES ................................. 1
CONTROLS AND FUNCTIONS ......................... 2
Front panel ................................................................. 2
Front panel display .................................................... 4
Rear panel.................................................................. 5
Remote control........................................................... 6
Using the remote control ........................................... 8
CONNECTIONS .................................................... 9
Connecting speakers and source components............ 9
Connecting the FM and AM antennas..................... 11
Connecting power cable .......................................... 11
PLAYBACK ..........................................................12
Playing a source....................................................... 12
Using the sleep timer ............................................... 13
FM/AM TUNING..................................................14
Using preset functions ............................................. 14
Receiving Radio Data System information
(Only for Europe model) ..................................... 18
SETTING THE OPTION MENU FOR EACH
INPUT SOURCE...............................................19
Option menu items................................................... 19
TROUBLESHOOTING .......................................20
SPECIFICATIONS...............................................23
■ About this manual
• y indicates a tip for your operation.
• The instructions in this manual describe the operation of this unit with the supplied remote control. You can also use the buttons or
knobs on the front panel if they have the same or similar names as those on the remote control.
This unit allows you to:
◆ Listen to FM and AM radio stations (see page 14)
◆ Use the remote control of this unit to operate a Yamaha
CD player (see page 7)
◆ Save power by using the AUTO POWER STANDBY
function (see page 19)
Please check that you received all of the following parts.
CONTENTS
INTRODUCTION
PREPARATION
BASIC OPERATION
ADVANCED OPERATION
ADDITIONAL INFORMATION
USEFUL FEATURES
SUPPLIED ACCESSORIES
Remote control
AM loop antenna
Batteries (x2)
(AA, R6, UM-3)
Indoor FM antennas
*
One of the above is supplied depending on the region of purchase.

Yamaha R-S201 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	500 mV
Audio output channels	- channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.2 %
Dynamic power per channel (4 Ohm)	165 W
Dynamic power per channel (8 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	100 W
FM antenna ports quantity	1
Ethernet LAN	No
Supported radio bands	AM, FM
Display	LCD
Product color	Silver
Volume control	Rotary
Apple docking compatibility	Not supported
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W

Weight and Dimensions

Depth	322 mm
Width	435 mm
Height	141 mm
Weight	6700 g
