4-4. REC OUT SWITCH/DOCK TYPE
REC OUT SWITCH: REC OUT switch is detected.
The voltage at 97 pin (REC) of the IC502 is displayed. (Reference voltage: 5.0 V=255)
When the A/D conversion value of the REC OUT switch becomes out of the specified range, normal operation
will not be available.
In that case, check the constant of voltage dividing resistor, solder condition, etc. Refer to table.
DOCK TYPE: DOCK type is detected.
The voltage at 69 pin (DOCK_TYP) of the IC502 is displayed. (Reference voltage: 5.0 V=255)
REC:155DK:255
A/D conversion value
(5.0 V=255)
16 – 46 47 – 77 78 – 108 109 – 139 140 – 171 172 – 203 204 – 237 238 – 255
REC OUT selector PHONO DOCK TUNER CD SOURCE TAPE LINE 1 LINE 2
DOCK TYPE
REC OUT SWITCH
DESTINATION
MODEL
*
Mode switch setting of the YDS-12
DOCK type
Bluetooth
(YBA-10)
Wireless iPod
(YID-W10)
iPod
No connected
(YDS-11/12 (B
*
)) (YDS-12 (A
*
))
A/D conversion value (5.0 V=255) 0 – 32 82 – 109 110 – 146 147 – 175 238 – 255
A/D conversion value (5.0 V=255) 9 – 25 26 – 43 44 – 67 128 – 158 187 – 210
Destination U C R A G
A/D conversion value (5.0 V=255) 9 – 25
Model name R-S700
4-5. MODEL/DESTINATION
MODEL: Model name is detected.
The voltage at 72 pin (MODEL) of the IC502 is displayed. (Reference voltage: 5.0 V=255)
DESTINATION: Destination is detected.
The voltage at 71 pin (DEST) of the IC502 is displayed. (Reference voltage: 5.0 V=255)
DESTINATION
MODEL
REC OUT SWITCH
DOCK TYPE
MDL:018DS:019
