Description
3-1
3
EAU10411
Left view
12345
8769
10
1. Coolant reservoir (page 7-14)
2. Main fuse (page 7-34)
3. Tool kit (page 7-2)
4. Passenger seat lock (page 4-16)
5. Storage compartment (page 4-18)
6. Shock absorber assembly spring preload adjusting ring (page 4-19)
7. Shift pedal (page 4-11)
8. Engine oil drain bolt (page 7-11)
9. Engine oil filter cartridge (page 7-11)
10.Canister (page 7-11)
UB5L12E0.book Page 1 Wednesday, March 25, 2020 9:59 AM
