Instrument and control functions
4-16
4
EAU13435
Catalytic converter
The exhaust system contains catalytic
converter(s) to reduce harmful exhaust
emissions.
EWA10863
The exhaust system is hot after op-
eration. To prevent a fire hazard or
burns:
z Do not park the vehicle near
possible fire hazards such as
grass or other materials that
easily burn.
z Park the vehicle in a place
where pedestrians or children
are not likely to touch the hot
exhaust system.
z Make sure that the exhaust sys-
tem has cooled down before
doing any maintenance work.
z Do not allow the engine to idle
more than a few minutes. Long
idling can cause a build-up of
heat.
EAU62622
Seats
Passenger seat
To remove the passenger seat
1. Insert the key into the seat lock,
and then turn it clockwise.
2. While holding the key in that posi-
tion, lift the rear of the passenger
seat and pull it backward.
To install the passenger seat
1. Insert the projections on the front
of the passenger seat into the seat
holders as shown, and then push
the rear of the seat down to lock it
in place.
2. Remove the key.
Rider seat
To remove the rider seat
1. Remove the passenger seat.
2. Remove the center cover by re-
moving the screws.
1. Passenger seat lock
2. Unlock.
1. Projection
2. Seat holder
UB5L12E0.book Page 16 Wednesday, March 25, 2020 9:59 AM
