Right view
1 2 3 4
8
7 6 59
1. Fuse box (page 7-34)
2. Battery (page 7-32)
3. Fuel tank cap (page 4-13)
4. Headlight (page 7-36)
5. Engine oil filler cap (page 7-11)
6. Engine oil level check window (page 7-11)
7. Brake pedal (page 4-12)
8. Rear brake light switch (page 7-23)
9. Rear brake fluid reservoir (page 7-24)
