Yamaha R3 2021 - Replacing the License Plate Light Bulb

Periodic maintenance and adjustment
7-37
7
EAU62670
Replacing the license plate
light bulb
1. Remove the mudguard by remov-
ing the quick fasteners.
2. Remove the rear fender lower
panel by removing the bolts and
screws.
3. Remove the license plate light
bulb socket (together with the
bulb) by pulling it out.
4. Remove the burnt-out bulb by
pulling it out.
5. Insert a new bulb into the socket.
6. Install the socket (together with
the bulb) by pushing it in.
7. Install the rear fender lower panel
by installing the bolts and screws.
8. Install the mudguard by installing
the quick fasteners.
1. Mudguard
2. Quick fastener
1
2
1. Bolt
2. Screw
3. Rear fender lower panel
1. License plate light bulb
2. License plate light bulb socket
3
2
1
2
2
1
2
1
