5-35
5
Compression damping force
(YXE10WRCN)
Fast compression damping force
To increase the fast compression damping
force and thereby harden the compression
damping, turn the fast compression damping
force adjusting bolt in direction (a). To de-
crease the fast compression damping force
and thereby soften the compression damp-
ing, turn the adjusting bolt in direction (b).
Compression damping force settings:
Minimum (soft):
1
Standard:
2
Maximum (hard):
3
1. Fast compression damping force adjusting bolt
Front fast compression damping force set-
tings:
Minimum (soft):
26 click(s) in direction (b)
Standard:
12 click(s) in direction (b)
Maximum (hard):
1 click(s) in direction (b)
1
(a)
(b)
