5-36
5
When adjusting the damping force settings,
turn the adjuster in direction (a) until it stops,
and then count the clicks in direction (b).
Slow compression damping force
To increase the slow compression damping
force and thereby harden the compression
damping, turn the slow compression damp-
ing force adjusting screw in direction (a). To
decrease the slow compression damping
force and thereby soften the compression
damping, turn the adjusting screw in direction
(b).
Rear fast compression damping force set-
tings:
Minimum (soft):
26 click(s) in direction (b)
Standard:
12 click(s) in direction (b)
Maximum (hard):
1 click(s) in direction (b)
1. Slow compression damping force adjusting screw
Front slow compression damping force set-
tings:
Minimum (soft):
25 click(s) in direction (b)
Standard:
12 click(s) in direction (b)
Maximum (hard):
1 click(s) in direction (b)
