AUDIO SECTION
Minimum RMS Output Power per Channel
8 ohms, 20 Hz to 20 kHz, 0.025% THD
.......................................................
80W+80W
6 ohms, 20 Hz to 20 kHz, 0.05% THD
.......................................................
90W+90W
Maximum Power (EIAJ)
[General model only]
8 ohms, 1 kHz, 10% THD......................
130W
6 ohms, 1 kHz, 10% THD......................
150W
Dynamic Power per Channel
(by IHF Dynamic Headroom measuring
method)
8/6/4/2 ohms....................120/140/180/200W
Power Band Width
8 ohms, 40W, 0.05% THD
.............................................10 Hz to 50 kHz
Damping Factor (SPEAKERS A)
8 ohms, 20 Hz to 20 kHz
.............240 or more
Input Sensitivity/Impedance
PHONO MM......................2.5 mV/47 k-ohms
CD/TAPE 1/VCR·TAPE 2/LD·TV
.........................................150 mV/47 k-ohms
Maximum Input Signal
PHONO MM
1 kHz, 0.003% THD ........................115 mV
Output Level/Impedance
REC OUT (PHONO).......150 mV/1.5 k-ohms
Headphones Jack Rated Output/Impedance
Output Level (8 ohms, 0.025% THD) .....0.3V
Impedance .....................................680 ohms
Frequency Response (20 Hz to 20 kHz)
CD/TAPE 1/VCR·TAPE 2/LD·TV
......0±0.5 dB
RIAA Equalization Deviation
PHONO MM ....................................0±0.5 dB
Total Harmonic Distortion (20 Hz to 20 kHz)
PHONO MM to REC OUT
3V....................................................0.003%
CD/TAPE 1/VCR·TAPE 2/LD·TV
to SP OUT
40W/8 ohms......................................0.01%
Signal-to-Noise Ratio (IHF-A Network)
PHONO MM (5 mV Input Shorted).......88 dB
CD DIRECT AMP SW: ON
(Shorted)
.........................................................110 dB
Residual Noise (IHF-A Network)
CD DIRECT AMP SW: ON.....................35
µV
PURE DIRECT SW: ON.........................90
µV
Channel Separation
CD/TAPE 1/VCR·TAPE 2/LD·TV
(Input 5.1 k-ohms Terminated, 1 kHz)
...........................................................65 dB
Tone Control Characteristics
BASS: Boost/cut...............±10 dB (20 Hz)
Turnover Frequency...........350 Hz
TREBLE: Boost/cut .............±10 dB (20 kHz)
Turnover Frequency..........3.5 kHz
Continuously variable LOUDNESS Control
(Level related equalization)
Attenuation............................ –30 dB (1 kHz)
VIDEO SECTION
Input Level/Impedance...........1 Vp-p/75 ohms
Output Level/Impedance ........1 Vp-p/75 ohms
FM SECTION
Tuning Range
[U.S.A. and Canada models]
..........................................87.5 to 107.9 MHz
[Australia and General models]
..........................................87.5 to 108.0 MHz
50 dB Quieting Sensitivity (IHF, 75 ohms)
Mono .................................1.55 µV (15.1 dBf)
Stereo...................................21 µV (37.7 dBf)
Usable Sensitivity (75 ohms)
(30 dB S/N Quieting, 1 kHz, 100% mod.)
.............................................0.8 µV (9.3 dBf)
DIN, Mono (S/N 26 dB) ........................0.9 µV
DIN, Stereo (S/N 46 dB)........................24 µV
Image Response Ratio
............................45 dB
IF Response Ratio
...................................70 dB
Spurious Response Ratio.........................70 dB
AM Suppression Ratio..............................55 dB
Capture Ratio ..........................................1.5 dB
Alternate Channel Selectivity ..................85 dB
Signal-to-Noise Ratio (IHF)
Mono/Stereo ..............................80 dB/75 dB
Harmonic Distortion (1 kHz)
Mono/Stereo .....................................0.1/0.2%
Stereo Separation (1 kHz)......................50 dB
Frequency Response
20 Hz to 15 kHz..............................0 ±1.5 dB
AM SECTION
Tuning Range
[U.S.A., Canada and General models]
.............................................530 to 1,710 kHz
[
Australia model
] .................531 to 1,611 kHz
Usable Sensitivity..............................100 µV/m
Selectivity................................................32 dB
Signal-to-Noise Ratio..............................50 dB
Image Response Ratio ...........................40 dB
Spurious Response Ratio .......................50 dB
Harmonic Distortion (400 Hz)...................0.3%
AUDIO SECTION
Output Level/Impedance
FM (100% mod., 1 kHz)
..........................................500 mV/2.2 k-ohm
AM (30% mod., 400 Hz)
..........................................150 mV/2.2 k-ohm
GENERAL
Power Supply
[U.S.A. and Canada models]
..............................................AC 120V, 60 Hz
[Australia model] ...................AC 240V, 50 Hz
[General model]
....................AC 110/120/220/240V, 60/50 Hz
Power Consumption
[U.S.A. model] ......................................190W
[Canada model] .......................250W, 320VA
[Australia and General models] ............210W
Maximum Power Consumption
[General model only] ............................450W
AC Outlets
2 SWITCHED OUTLETS
[U.S.A., Canada and General models]
..........................................100W max. total
1 SWITCHED OUTLET
[Australia model]................100W max. total
Dimensions (W x H x D)
......................................435 x 151 x 389.8 mm
(17-1/8” x 5-15/16” x 15-3/8”)
Weight............................9.5 kg (20 lbs. 14 oz.)
Accessories...........................AM loop antenna
Indoor FM antenna
Remote control transmitter
Batteries
Antenna adapter
(U.S.A. and Canada models only)
Specifications are subject to change without
notice.
SPECIFICATIONS
