En 103
You can change the settings of the sound programs and surround decoders using the
TV screen.
1
Press ON SCREEN.
2
Use the cursor keys to select “Sound Program” and press ENTER.
3
Use the cursor keys ( / ) to select a sound program to be
configured and press the cursor key ( ).
You can still switch the sound program by using cursor keys ( / ) after step 3.
4
Use the cursor keys ( / ) to select an item and press ENTER.
To return to the previous screen during menu operations, press RETURN.
To restore the default settings for the selected sound program, select “Reset”.
5
Use the cursor keys to select a setting and press ENTER.
6
To exit from the menu, press ON SCREEN.
Configuring sound programs/surround
decoders (Sound Program menu)

Table of Contents

Other manuals for Yamaha RX-A2010

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yamaha RX-A2010 and is the answer not in the manual?

Yamaha RX-A2010 Specifications

General IconGeneral
Receiver type-
RMS rated power1980 W
Audio output channels9.2 channels
Dynamic power per channel (4 Ohm)285 W
Dynamic power per channel (8 Ohm)165 W
Power output per channel (1KHz@8 Ohm)220 W
Power output per channel (20-20KHz@8 Ohm)140 W
HDMI in8
Remote control in2
Composite video in5
Digital audio coaxial in3
Component video (YPbPr/YCbCr) in4
Component video (YPbPr/YCbCr) out1
12V triggerYes
Ethernet LANNo
Supported radio bandsAM, FM
Product colorTitanium
Audio decodersDolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS-HD Master Audio
Power consumption (standby)0.3 W
Weight and Dimensions IconWeight and Dimensions
Depth467 mm
Width435 mm
Height192 mm
Weight17100 g
