Yamaha RX-A2010 User Manual

En 152
• The area around the video/audio output jacks is marked in white on the actual product.
Reference diagram (rear panel)
+12V 0.1A MAX.
AC IN
TRIGGER
OUT
DOCK
FM
75Ω
ANTENNA
YP
B P R
YP B P R
YP B P R
OPTICAL
AV OUT
R
L
HDMI OUT
ARC
1
1
1
2
2
HDMI
(1 BD/DVD)
MONITOR OUT/
ZONE OUT
MONITOR OUT/ZONE OUT
IN OUT
2
IN OUT
AV 1
AV 1
AV 3
AV 2AV 3AV 4AV 5AV 6AV 7
1
2
REMOTE
COMPONENT VIDEO
AV 3 AV 4AV 2AV 1
AUDIO 4 MULTI CH INPUT
ZONE OUT
AUDIO 3AUDIO 2
(3 CD)
AUDIO 1
(2 TV)
(1 BD/DVD)
CENTER
SUBWOOFER ZONE 2 ZONE 3FRONT
SURROUND SUR. BACK
SPEAKERS
CENTER FRONT
ZONE 2/ZONE 3/R.PRESENCE
SURROUND BACK
BI–AMP
ZONE 2/ZONE 3/F.PRESENCE/
R
5
OPTICAL
4
OPTICAL
3
COAXIAL
2
COAXIAL
1
COAXIAL
6
L
SURROUND
R L
R
R
R
L
L
L
RS-232C
AMGND
(4 RADIO)
HD Radio
SIRIUS
PHONO
NETWORK
A
AV 2
B
C
AV 4
D
PRE OUT
SUBWOOFER
CENTER
FRONT SURROUND SUR. BACK
(SINGLE) (FRONT)
(REAR)
GND
EXTRA SP1
EXTRA SP2
SINGLE

Yamaha RX-A2010 Specifications

General

Receiver type	-
RMS rated power	1980 W
Audio output channels	9.2 channels
Dynamic power per channel (4 Ohm)	285 W
Dynamic power per channel (8 Ohm)	165 W
Power output per channel (1KHz@8 Ohm)	220 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote control in	2
Composite video in	5
Digital audio coaxial in	3
Component video (YPbPr/YCbCr) in	4
Component video (YPbPr/YCbCr) out	1
12V trigger	Yes
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Titanium
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS-HD Master Audio
Power consumption (standby)	0.3 W

Weight and Dimensions

Depth	467 mm
Width	435 mm
Height	192 mm
Weight	17100 g
