A1-6. DSP FULL SURROUND BACK
The audio signal is output to only SURROUND BACK L/R channels in digital full bit without including the head
margin.
A1-7. DSP FULL SUBWOOFER
The audio signal is output to only SUBWOOFER channels in digital full bit without including the head margin.
A2-2. DIRECT VL
The analog input audio signal is output to FRONT L/R in PURE DIRECT mode.
VL: Voltage Low, RY101 on MAIN P.C.B.: On
A1-6
DSPFULLSB
A1-7
DSPFULLSW
A2-2
DIRECT:VL
Input level Volume
SPEAKER OUTPUT
SUBWOOFER
OUTPUT
FRONT L/R CENTER
SURROUND
L/R
SURROUND
BACK L/R
PRESENCE/
ZONE2
Both ch, -20 dBm +6.5 dB +13.0 dBm - ∞ - ∞ - ∞ - ∞ - ∞
Input level Volume
SPEAKER OUTPUT
SUBWOOFER
OUTPUT
FRONT L/R CENTER
SURROUND
L/R
SURROUND
BACK L/R
PRESENCE/
ZONE2
Both ch, -20 dBm +6.5 dB +13.0 dBm - ∞ - ∞ - ∞ - ∞ - ∞
A2. DIRECT AUDIO
This menu is used to check audio signal route of DIRECT mode.
A2-1. DIRECT VH
The analog input audio signal is output to FRONT L/R in PURE DIRECT mode.
VH: Voltage High, RY101 on MAIN P.C.B.: Off
A2-1
DIRECT:VH
INPUT: AV5 ANALOG
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
INPUT: AV5 ANALOG
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
