● Details of Self-Diagnostic Function menu
A1. DSP AUDIO
This menu is used to check audio signal route via DSP.
A1-1. DSP MARGIN
The audio signal is output including the head margin via DSP.
* When input source is stereo, signal is assigned as below.
Front L: Front L, Center, Surround L, Surround Back L, Presence L
Front R: Front R, Surround R, Surround Back R, Presence R
Front L +10 dB: Subwoofer
A1-2. DSP NON MARGIN
The SUBWOOFER signal is output including the head margin via DSP.
The audio signal other than SUBWOOFER is output without including the head margin via DSP.
A1-3. INVALID ITEM
Not for service.
A1-2
DSPNONMARGIN
A1-3
INVALIDITEM
A1-1
DSPMARGIN
A1-4. DSP FULL CENTER
The audio signal is output to only CENTER channel in digital full bit without including the head margin.
A1-4
DSPFULLC
A1-5. DSP FULL SURROUND
The audio signal is output to only SURROUND L/R channels in digital full bit without including the head margin.
A1-5
DSPFULLSUR
