N1-1
IPADCHK:OK
N1-2
MACADCHK:OK
OK: Connected (IP address obtained)
NG: No traffic / Disconnected
OK: Normal
NG: Unwritten
N1-2. MAC ADDRESS CHECK
MAC address information is checked.
N1. NETWORK
This menu is used to check signal route of NETWORK.
Connect between NETWORK port of this unit and LAN port of broadband with a network cable.
* When the network condition varies while sub-menu is displayed (e.g., the network is deactivated once), the correct
result will not be displayed.
In that case, once turn off the power to this unit, then start up the self-diagnostic function again and select this
menu.
N1-1. IP ADDRESS CHECK
IP address obtained is checked.
N1-3
LINENOISE10
N1-4
LINENOISE100
N1-3. LINE NOISE 10
Not for service.
N1-4. LINE NOISE 100
Not for service.
